TMC's ISO 46 Oil is a long-life, premium compressor lubricant based on novel, proprietary technology. It incorporates the highest quality, thermally stable synthetics fortified with premium non-detergent additives for maximum protection at high temperatures. It lasts up to 8,000 hours, effectively reducing maintenance and waste oil disposal costs.

Improves Compressor Efficiency
Controls Foam and Reduces Wear
Resists Water Contamination
Resists Heat and Oxidation

APPLICATIONS

Single and multistage rotary screw, vane, centrifugal and reciprocating compressor crankcases and cylinders
Vacuum Pumps
Pressure Washer Pumps
Gears, Bearings, Blowers and Pumps

PHYSICAL PROPERTIES

Iso Viscosity Grade	46	ASTM D2422
Kinematic Viscosity @ 100 °C, cSt	7.4	ASTM D445
Kinematic Viscosity @ 40 °C, cSt	43.7	ASTM D445
Viscosity Index	132	ASTM D2270
Color	L0.5	ASTM D1500
Flash Point °C (°F)	262 (504)	ASTM D92
Fire Point °C (°F)	284 (543)	ASTM D92
Pour Point °C (°F)	-38 (-36)	ASTM D97
Four Ball Wear Test, mm scar 75 °C, 1200 rpm, 40kg, 1 hr	0.41	ASTM D4172
Acid Number (TAN)	0.29	ASTM D665
Copper Corrosion, 121°C, 3hr	1A	ASTM D130
Demulsibility	40-40-0 (10)	ASTMD1401
FZG Failure Stage, A/8.3/90	-	DIN 51534
Foam Characteristics, ml Seq. 1 Seq. II Seq. III	0/0 0/0 0/0	ASTM D892

MATERIAL COMPATIBILITY

TMC ISO-46 is compatible with petroleum oils and most synthetic oils, seals, paints and materials including the following:

Gases:
- Nitrogen, Hydrogen, Helium, Carbon Monoxide
- Carbon Dioxide (dry), Ethylene, Methane
- Propane, Butane, Propylene, Butylenes
- Natural Gas, Benzene, Butadiene
- Hydrogen Sulfide
- Synthetic Gas, Sulfur Dioxide
Paints
- Epoxy, Oil Resistant Alkyd, Acrylic Enamel
Plastics
- Acetal, ABS, Phenolic, Polyamide-imide
- Polyamide (Nylon)
- Polycarbonate
- Polyester, Polyetherimide, Polyimide
- Polyphenylene oxide, Polystyrene, Polysulfone
- PTFE (Teflon), Terephthalate
Elastomers
- Fluoroelastomer, Nitrile
- Polyacrylate, TFE/P, Poly Urethane

TMC ISO-46 is NOT compatible with polyalkylene glycol or silicone oils.
