FLUTEC PP1

Flutec PP1 is used widely to replace 3M™ Fluorinert™ Electronic Liquid FC-72, and 3M Performance Fluid PF-5040 in gross leak testing, immersion cooling, and heat transfer applications.  Flutec PP1 is REACH Certified.



APPLICATIONS

• Heat Transfer
• Electronics Manufacturing
• Precision Cleaning
• Gross Leak Testing



PHYSICAL PROPERTIES COMPARISON

	3M FC-72	PF-5040	Flutec PP1
Appearance	Clear Colorless	Clear Colorless	Clear Colorless
Molecular Weight	338		338
Boiling Point (1 atm)	56 oC	56°C	57  oC
Pour Point	-90 oC	-90°C	-90 oC
Estimated Critical Temperature	449K	451 K	451K
Estimated Critical Pressure	1.83 x 106 pascals	1.83 x 106 Pa	1.834 x 106 pascals
Vapor Pressure	30.9  x 103 pascals	30.9 x 103 Pa	29.4 x 103 pascals
Latent Heat of Vaporization (at normal boiling pt)	88J/g	88 J/g	85.5 J/g
Liquid Density	1680 kg/m3	1680 kg/m3	1682 kg/m3
Kinematic Viscosity	0.38 centistokes	0.38 centistokes	0.39 centistokes
Absolute Viscosity	0.64 centipoise	0.64 centipoise	0.656 centipoise
Liquid Specific heat	1100 J kg-1 C-1	1.05 J g-1 °C--1	1090 J kg-1 C-1
Liquid Thermal Conductivity	0.057 W m-1 oC-1	0.057 W m-1 °C-1	.065 W m-1 oC-1
Co-efficient of Expansion	0.00156  oC-1	0.0016 °C-	0.00159 oC-1
Surface Tension	10 dynes/cm	12 dynes/cm	11.1 dynes/cm
Refractive Index	1.251	1.249	1.2564
Water Solubility	10 ppmw	10 ppmw	10 ppmw
Solubility in Water	<5 ppm	<5 ppmw	<0.1 ppm
Ozone Depletion Potential (ODP)	0	0	0
Dielectric Strength	38 kV, 0.1” gap		>16 kV/mm
Dielectric Constant	1.75
Electrical Resistivity	1015 ohm cm		> 1013 ohm.cm



PERFORMANCE

Dynamic Viscosity

TEMPERATURE (°C)	RESULT (mPa s)
-100	21.5
-80	7.5
-60	3.6
-40	2.15
-20	1.5
0	0.99
20	0.72
40	0.54
60	0.41
80	0.32
100	0.257
115	0.22



Density

TEMPERATURE (°C)	DENSITY (g/ml)
10	1.7610
20	1.7326
30	1.7031
40	1.6728
50	1.6410



Thermal Conductivity of the Vapor (mW/m/K) PP1

0	6.1
20	7.9
40	9.6
60	11.3
80	13.1
100	14.8
120	16.6
140	18.3
160	20.1
180	21.8
200	23.5
220	25.3
240	27.0



MATERIAL COMPATIBILITY

Compatible with most construction materials.



SAFETY, HANDLING AND STORAGE

Although Flutec PP1 is considered biologically and chemically inert, good laboratory practice should be observed when handling.  Flutec PP1 has an indefinite shelf life if properly stored in its original sealed container.  Safety data sheets are available on request.



ENVIRONMENTAL

This product has a global warming potential of greater than 150

TSCA - This product is registered on the TSCA inventory under cas number: 86508-42-1 - perfluorocompounds C5-C18.  This is a registration for a class 2 substance within the UVCB group.  (Variable composition)

VOC – PP1 although Volatile does not classify as a VOC under the current EPA definition of  " Volatile organic compounds (VOC) means any compound of carbon, excluding carbon monoxide, carbon dioxide, carbonic acid, metallic carbides or carbonates, and ammonium carbonate, which participates in atmospheric photochemical reactions.

PFAS – There is no current internationally agreed definition of PFAS.  The current ECHA & EPA definition is  substances containing one fully fluorinated methyl group (-CF3) or fully fluorinated methylene group (-CF2-) without any hydrogen, chlorine, bromine or iodine atom attached to it.

Under this ‘family’ definition Flutec fluids are classified as PFAS products, however, they do not have the properties of concern that functional PFAS products have.  Flutec PP1 is NOT toxic and it does NOT Bioaccumulate.

F-gas : this item is included in the f-gas regulations April 2024.



DISPOSAL & RECYCLING
